Mixed Gas Fire Monitoring System

The LFCM7005 pressure monitoring controller is the monitoring host for the entire mixed gas fire fighting monitoring system, which can monitor and display the value of each pressure point in the system in real time, alarm status and operation of the system. Perform the unified configuration of system parameters and monitor the status of the entire system in real time, 24 hours.

The mixed gas fire-fighting monitoring system consists of a pressure monitoring control cabinet and a pressure sensor with a 485 signal output. The controller collects signals from the sensor in real time and issues alarms to pressure points that exceed the defined upper and lower limits and display them on the touch screen. It features simple operation, clear display and easy maintenance.

Fully meets the standard for inspection of electronic products against fire. It is connected to the pressure sensor with signal output 485, which is convenient and flexible to build the entire gas monitoring system.

The 4G remote transmission module can be configured to facilitate users to perform remote pressure monitoring. Enables the adoption of 485 communication, with super long communication distance.

Offers control via a 10-inch screen, with extremely strong operability performance.

Technical parameters

• Installation method: Wall mounting;

• Power supply: AC220V;

• Output power: DC2V

• Communication method: MODBUS-RS485/4G;

• Communication distance: 1000 meters reliable;

• Display: 10 inch TFT LCD touch screen;

• Alarm: audible and light alarm;

• Protection level: IP30;

• Environmental requirements: temperature -10 ~ 45 ?, humidity <95% RH (40 ?), altitude <4500 meters;

• Alternative power supply: DC24V battery
