| Model | LFP1500W | LFP1600J-V | LFP1600J | LFP1600JD | LFP2500W | LFP2600J-V | ||
| Voltage | 24V DC | 36V DC | ||||||
| Inlet Water Pressure | 0.2MPa | 0.2MPa | ||||||
| Working Pressure | 0.5MPa | 0.7MPa | 0.5MPa | 0.5MPa | 0.7MPa | 0.5MPa | ||
| Working Current | ≤3.2A | ≤3.7A | ≤3.0A | ≤2.8A | ≤1.6A | ≤2.0A | ≤1.8A | |
| Working Flow Rate | ≥3250ml/min | ≥2800ml/min | ≥3200ml/min | ≥3250ml/min | ≥2800ml/min | ≥3200ml/min | ||
| Open Flow | ≥5000ml/min | ≥4000ml/min | ≥4500ml/min | ≥5000ml/min | ≥4000ml/min | |||
| Bypass Pressure | 0.85-1.05MPa | 0.9-1.1MPa | 0.85-1.05MPa | 0.85-1.05MPa | 0.9-1.1MPa | |||
| Maximum Current | ≤4.2A | ≤4.0A | ≤2.5A | |||||
