| Model | LFP11000J-V1 | LFP11000W-A | LFP21000J-V1 | LFP21000J-FD1 | LFP21000W-A | LFP21000W-FD1 |
| Voltage | 24V DC | 36V DC | ||||
| Inlet Water Pressure | 0.2MPa | 0.2MPa | ||||
| Working Pressure | 0.7MPa | 0.7MPa | ||||
| Working Current | ≤5.0A | ≤3.5A | ||||
| Working Flow Rate | ≥5000ml/min | ≥5000ml/min | ||||
| Open Flow | ≥6000ml/min | ≥6000ml/min | ≥6500ml/min | |||
| Bypass Pressure | 1.1-1.3Mpa | 0.95-1.15MPa | 1.1-1.3Mpa | 1.05-1.2MPa | 1.05-1.2MPa | 1.0-1.2MPa |
| Maximum Current | ≤6.0A | ≤4.5A | ||||
