The LF10-W series pressure switch can continuously measure and control the pressure of automatic water supply systems. This series of pressure switches is widely used as a matching component in water pumps or other water supply systems.
LF10-WR can prevent the water pump from starting and running below a certain water pressure, and the switch will automatically close when the water pressure returns to the preset value. The switch with a handle can be manually operated to turn on and operate the system, making it easy to use.
| Model | Pressure regulation range kgf/cm² | Differential pressure adjustment range kgf/cm² | Factory setting kgf/cm² | Rated voltage and current | Contact Method | Interface Standard |
| LF10-WS (LF10A-WS) | 2.0-7.0 | 1.0-2.0 | 1.5-2.5 | 120VAC, 20A (120VAC, 26A) 240VAC, 12A (240VAC, 26A) | Normally Closed | 1/4NPT inner or outer screw |
| 2.0-7.0 | 1.5-2.5 | 2.0-3.5 | ||||
| 2.5-10.5 | 2.0-3.5 | 6.0-8.0 | ||||
| LF10-WR (LF1OA-WR) | 5.5-1.0 | 1.0-2.0 | 3.5-2.0 | 240VAC, 20A (120VAC, 26A) 240VAC, 12A (240VAC, 26A) | Normally Open | 1/4NPT inner or outer screw |
| 7.0-2.0 | 1.5-2.5 | 7.0-5.3 | ||||
| 10.5-2.5 | 2.0-3.5 | 8.8-6.7 |
Unit conversion: 1kgf/cm ²=14.2psi, 1bar=14.5psi. Other interfaces can be customized according to customer requirements.
