Paper making, refine sugar, mining and metallurgy, drainage, environmental protection.
Water conservancy and hydraulic engineering, iron and steel, petroleum, Pharmaceutical, various beverages.
Petroleum, organic liquid, inorganic liquid, cryogenic fluid.
High precision linear stability.
Good reliability and anti-interference performance.
No zero drift, strong anti-interference ability.
| Drift Diameter | 4-300mm |
| Max. Flow | 10m/s |
| Output Signal | 4-20mA, HART, RS485 (optional) |
| Electrical Connection | Flange connection, clamp connection, thread connection |
| Accuracy | 1.00% |
| Power Supply | 24VDC (integrated), Battery powered (integrated) |
| Consumed Power | within 0.5w |
| Nominal Pressure | 10MPa, 6.3MPa, 2.5MPa, 1.6MPa |
| Ambient Temperature | -10°C~60°C |
| Flange Material | Stainless steel (304, 316, 316L) |
| Protection Grade | IP65 |
| Nominal diameter(mm) | Flow Range (m³/h) | Fluid Temperature Range (℃) | Nominal Pressure (MPa) | |
| Integrated | Explosion-proof Type | |||
| 10 | 0.2-1.2 | -10℃~80℃, above 80℃ need customization | -20℃~70℃ | <DN2001. 6MPa DN250-3001.0MPa pressure beyond this range need customization |
| 15 | 0.4-6 | |||
| 25 | 1.2-12 | |||
| 40 | 3-30 | |||
| 50 | 5-50 | |||
| 80 | 12-120 | |||
| 100 | 20-200 | |||
| 150 | 40-400 | |||
| 200 | 80-800 | |||
| 250 | 120-1200 | |||
| 300 | ||||
