High precision, high stability.
Low noise, suitable for home use.
Long life, durable.
Easy tube replacement without tools.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weightt | Working Environment | Rollers |
P303ADB | Built-in mounting hole | Brush DC motor | Power-on operation | Fixed flow rate | DC12V, DC24V | ≤12W | 300g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers+2 training wheels(4 rollers are available) |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC12V, DC24V | 210～270 | 16# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 380～540 | 25# | ||
| 550～730 | 17# | ||
