get a quote
| Model | LFP1050W-B | LFP1075W-B | LFP1100W-B | LFP1150W-B | LFP1200W-B |
| Voltage | 24V DC | ||||
| Inlet Water Pressure | 0.2MPa | ||||
| Working Pressure | 0.5MPa | ||||
| Working Current | ≤0.7A | ≤0.9A | ≤1.2A | ≤1.5A | ≤1.9A |
| Working Flow Rate | ≥600ml/min | ≥750ml/min | ≥980ml/min | ≥1500ml/min | ≥1900ml/min |
| Open Flow | ≥1600ml/min | ≥1800ml/min | ≥2000ml/min | ≥2200ml/min | ≥2500ml/min |
| Bypass Pressure | 0.8-1.0MPa | ||||
| Maximum Current | ≤1.0A | ≤1.2A | ≤1.4A | ≤2.0A | ≤2.5A |
