| Model | LFP1600J-A | LFP1600J-V1 | LFP1600W | LFP2600J-V1 | LFP2600J-A | LFP2600W | ||
| Voltage | 24V DC | 36V DC | ||||||
| Inlet Water Pressure | 0.2MPa | 0.2MPa | ||||||
| Working Pressure | 0.7MPa | 0.5MPa | 0.7MPa | 0.7MPa | 0.5MPa | 0.7MPa | ||
| Working Current | ≤3.3A | ≤3.0A | ≤4.0A | ≤2.2A | ≤1.9A | ≤2.2A | ||
| Working Flow Rate | ≥3200ml/min | ≥3600ml/min | ≥3200ml/min | ≥3200ml/min | ≥3600ml/min | ≥3200ml/min | ||
| Open Flow | ≥4500ml/min | ≥6000ml/min | ≥4500ml/min | ≥6000ml/min | ||||
| Bypass Pressure | 0.85-1.05MPa | 1.0-1.2MPa | 0.85-1.05MPa | 1.0-1.2MPa | 0.85-1.05MPa | 0.85-1.05MPa | ||
| Maximum Current | ≤4.3A | ≤4.5A | ≤3.0A | ≤2.5A | ≤2.8A | |||
