Adopt stepper motor, high reliability
Low noise, exemption of maintenance
High accuracy and long time running ability
Support PWM speed control
| SPECIFICATIONS | |||||||||
| Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
| PC101ST | Table type, Wall type | Stepper Motor | Driver Control | Precise adjustable flow control | DC24V | ≤12W | 410g | Temperature 0-45℃ Relative Humidity <85%RH | Standard with 2 Rollers(3 Rollers, 6 Rolers are available) |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC24V | 3～18 | 1*3 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 10～60 | 2*4 | ||
| 20～140 | 3*5 | ||
| 30～200 | 4*6 | ||
