| Model | LFP11000J-V | LFP11000W | LFP21000J-V | LFP21000J-FD | LFP21000W | LFP21000W-FD |
| Voltage | 24V DC | 36V DC | ||||
| Inlet Water Pressure | 0.2MPa | 0.2MPa | ||||
| Working Pressure | 0.7MPa | 0.7MPa | ||||
| Working Current | ≤4.5A | ≤3.2A | ||||
| Working Flow Rate | ≥4500ml/min | ≥4500ml/min | ||||
| Open Flow | ≥5500ml/min | ≥6000ml/min | ≥5500ml/min | ≥6000ml/min | ||
| Bypass Pressure | 1.05-1.25Mpa | 0.95-1.15Mpa | 1.05-1.25Mpa | 1.05～1.2MPa | 1.0-1.2MPa | |
| Maximum Current | ≤5.8A | ≤4.0A | ||||
