High precision, long lifetime, durable.
Straight tube installation method to avoid residual stains (straight, U-shaped, L-shaped are available).
Waterproof pump head prevents water from entering the motor.
Whole detachable pump head, convenient for tube replacement and maintenance.
Low noise, smooth operation, fine-tunable pressure tube to avoid dripping.
Support PLC control, 485 Communication.
| Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
| P501ST | Built-in mounting hole | Stepper motor | Driver control (Optional with Driver PLC control) | Precise adjustable flow control | DC24V | ≤24W | 1430g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC24V | 10～780 | 24# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 10～1260 | 35# | ||
| 10～1600 | 36# | ||
