High precision, long lifetime, durable.
Straight tube installation method to avoid residual stains (straight, U-shaped, L-shaped are available).
Waterproof pump head prevents water from entering the motor.
Whole detachable pump head, convenient for tube replacement and maintenance.
Low noise, smooth operation, fine-tunable pressure tube to avoid dripping.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P501DB | Built-in mounting hole | Brush DC motor | Power-on operation | Fixed flow rate | DC12V, DC24V | ≤24W | 640g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC12V, DC24V | 990～1600 | 24# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 1480～2550 | 35# | ||
| 1800～2800 | 36# | ||
