LFW20 series temperature transmitter adopts high-precision platinum resistance, the probe rod is made of 304 stainless steel integrated processing, with strong corrosion resistance and excellent mechanical properties, can work stably for a long time. A variety of installation options, suitable fordifferent working conditions, widely used in petroleum, chemical, heating, hydrology, HVAC and other industrial site temperature measurement.
Measuring medium | Liquid or gas,etc. (compatible with contact materials) |
Measuring range | -50~300℃(see range parameter selection table for details) |
Output signal | 4~20mA/0-10V/RS485/PT100/PT1000 |
Supply voltage | 15~35VDC |
Accuracy | 0.25%FS, 0.5%FS |
Working environment | -40~85℃, 0~95%RH(No condensation) |
Housing material | Die-cast aluminum housing, 304stainless steel probe rod and casing |
Protection level | IP65. Note: this protection level refers to the level achieved after the electrical connection is complete |
The protection tube is made of 304 stainless steel with strong.
Corrosion resistance and excellent mechanical properties.
With reverse protection function.
High protection level up to IP65.
