① Self-priming type
| Model | Voltage | Inlet Water Pressure | Working Pressure | Working Current | Working Flow Rate | Open Flow | Bypass Pressure | Maximum Current | Self-priming Height |
| LFP1075ES | 24V DC | 0MPa | 0.5MPa | ≤1.3A | ≥800mL/min | ≥1100mL/min | 0.8-1.0MPa | ≤1.6A | ≥2.0m |
| LFP1075JS | ≥1200mL/min | ≤1.8A |  ≥3.0m | ||||||
| LFP1075S-P | ≥850mL/min | ≥1300mL/min | |||||||
| LFP1075S-P-B | ≥1000mL/min | ||||||||
| LFP1075S |
② Normal type
| Model | Voltage | Inlet Water Pressure | Working Pressure | Working Current | Working Flow Rate | Open Flow | Bypass Pressure | Maximum Current | Self-priming Height |
| LFP1075E | 24V DC | 0.2MPa | 0.5MPa | ≤1.0A | ≥750mL/min | ≥1800mL/min | 0.8-1.0MPa | ≤1.3A | / |
| LFP1075J | ≤0.9A | ≤1.2A | |||||||
| LFP1075W-P | |||||||||
| LFP1075W | 0.85-1.0MPa |
