LF42 series pressure switch is used in water supply pressure protection of water inlet. This series include two models LF42H(high pressure protection) and LF42L(low pressure protection). LF42H is the high pressure protection switch model. If the pressure of the pressure vessel transferred reaches the setting value while the vessel is full filled with water, the switch will cut off the circuit to make the pump stop. So the pump will not be damaged. LF42L is the low pressure protection switch. If the pressure of water inlet lower than set value, RO will not work and keep dewatering, then the switch will cut off the circuit to make the pump stop. It can prevent the booster pump still working without water which may lead to the damage of the circuit. If the pressure of the water inlet returns to the lowest set volume, the pump will work again.
| Model | LF42H | LF42L |
| Media | water | water |
| Pressure set range | cut off pressure: 2.5bar±0.5bar cut in pressure: 1.5bar±0.5bar | cut off pressure: ≤0.1 bar cut in pressure: ≥0.2 bar |
| Proof pressure | 18bar | 18bar |
| Durability | >40000 cycles | >40000 cycles |
| Working temperature | 5~45℃ | 5~45℃ |
| Switch type | Microswitch, normal close | Microswitch, normal open |
| Electrical rating | Voltage: 250V AC Current: 16A | Voltage: 250V AC Current:16A |
| Terminal | 4.8*0.8 blade | 4.8*0.8 blade |
| Connector | A quarter fast interface | A quarter fast interface |
Conversion: 1bar=14.5psi 1MPa=10bar
