LF16 pressure switches provide time tested, reliable control for automatic water systems. The switch is univesally acceptable for use as original equipment on water well pumps or pumping systems.
| Model | Min On (Cut-In) | Min Off (Cut-Out) | Differential | Factory Setting | Electrical 1Phase | Rating 3Phase | Contact | Connection | ||
| psi | psi | psi | psi | 120VAC | 240VAC | 240VAC | Arrange-ment | |||
| LF16 | 20 | 80 | 15-30 | 20-40 | 2HP | 3HP | 5HP | NC | 1/4 Male or Female NPT | |
| 15-30 | 30-50 | |||||||||
| 15-35 | 40-60 | |||||||||
| 40 | 100 | 20-35 | 70-100 | |||||||
| LF16-1 | 20 | 80 | 15-30 | 20-40 | 1.5HP | 2HP | 3HP | |||
| 15-30 | 30-50 | |||||||||
| 15-35 | 40-60 | |||||||||
| 40 | 100 | 20-35 | 70-100 | 2HP | 3HP | 5HP | ||||
Conversion: 1kgf/cm²=14.2psi 1bar=14.5psi
Other connections are available on request.
