LF40-B is provided with a snap action switching for higher current capacity, SPDT contact form and switch deadbands. It can be used together with air button for remote control purpose, which is widely used in food waste disposer, pumps for swimming pools and spas, hot tubs, sanitary equipment, medical equipment etc.
Model | LF40-B |
Good air tightness | There should be no leakage under 50 psi pressure |
Pressure range | <130mbar |
Service life | >40000 times |
Electrical performance | 10A, 125/250V |
Wiring form | 6.3×0.8 mm blade terminal |
Electrical circuit | NO-C |
Operating temperature | -10℃~85℃ |
Socket and cable | GB, power cord length 1200mm |
Air tube | 6mm tube, length 1000mm |
