Adopt stepping motor plus customized control module for precise control, high precision, long life.
2 inch color display screen shows the instant configuration data of the pump.
Support functions such as start-stop, direction change, calibration(different media), speed regulation, fixed quantity dispensing, fixed quantity dispensing at a set time, timing, reverse suction, etc.
Support three operation modes, namely fully automatic cycle, semi-automatic.
cycle, and manual operation.It also supports the replacement of three configured pump head components.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
PC302ST | Table type | Stepper motor | Driver Control | Precise adjustable flow control | DC24V | ≤20W | 983g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers+2 training wheels (4 rollers are available) |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC24V | 25～180 | 16# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
33～320 | 25# | ||
50～500 | 17# | ||
