Adopt DC motor, high cost-effective.
Simple structure, exemption of maintenance.
Adjustable run speed.
Smallvolume, large flow rate.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
PC203DB | Table type, Wall type | Brush DC motor | Driver Control | Precise adjustable flow control | DC24V | ≤8W | 322g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 Rollers (4 Rollers are available) |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC24V | 40～255 | 3*5 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 45～280 | 16# | ||
| 50～490 | 4*6 | ||
