Convenient and quick tube replacement
Simple structure, exemption of maintenance
Adjustable run speed
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
PC104DB | Table type, Wall type | Brush DC motor | Driver Control | Precise adjustable flow control | DC24V | ≤6W | 265g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC24V | 3～30 | 1*3 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
10～115 | 2*4 | ||
20～185 | 3*5 | ||
