Adopt brushless motor, super long lifespan
Simple structure, exemption of maintenance
Adjustable run speed
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
PC104BL | Table type, Wall type | Brushless DC Motor | Driver Control | Precise adjustable flow control | DC24V | ≤8W | 270g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC24V | 2～23 | 1*3 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
4～97 | 2*4 | ||
8～185 | 3*5 | ||
