The pump head with new quick disassembly and assembly structure, stable and reliable, convenient to repair and maintain.
Compact structure, single pump takes upless space.
Compatible to multiple specifications of tubes, covering a wide range of flow rates.
Transparent pump cover allows for real-time monitoring of pump operation.
Installation method can be customized.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P601DB | Stainless steel mounting plate as standard (customizable) | Brush DC motor | Power-on operation | Fixed flow rate | DC12V, DC24V | ≤32W | 670g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Sze | Tube Type |
| DC12V, DC24V | 330～1915 | 26# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 560～2930 | 35# | ||
| 725～4200 | 36# | ||
