High precision, high stability
Low noise, suitable for home use
Long life, durable
Easy tube replacement without tools
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P403DB | Stainless steel mounting plate, as standard (customizable) | Brush DC motor | Power-on operation | Fixed flow rate | DC12V, DC24V | ≤24W | 460g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers +2 training wheels |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC12V, DC24V | 825～1220 | 25# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
1320～1940 | 17# | ||
