Large flow
Low noise
Long life
Can transport viscous media in large quantities
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P402DB | Stainless steel mounting plate, as standard (customizable) | Brush DC motor | Power-on operaion | Fixed flow rate | DC12V, DC24V | ≤36W | 630g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers+2 training wheels |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC12V, DC24V | 1965～2900 | 35# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
2800～4200 | 36# | ||
