Convenient to start and stop, adjustable speed, positive reverse.
Low noise, quiet and stable.
Support PLC control, 485 Communication.
Installation method can be customized.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P302ST | Built-in mounting hole | Stepper motor | Driver control (Option with Driver and PLC control) | Precise adjustable flow control | DC24V | ≤12W | 640g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers +2training wheels (4 rollers are available) |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC24V | 1～160 | 16# | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 1～330 | 25# | ||
| 1～420 | 17# | ||
