get a quote
Large flow, small volume.
Low noise, long life, high precision.
Positive and negative rotation.
Easy tube replacement without tools.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P203DB | Stainless steel mounting plate as standard (customizable) | Brush DC motor | Power-on operation | Fixed flow rate | DC12V, DC24V | ≤10W | 160g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers(4 rollers are available) |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC12V, DC24V | 125～305 | 3*5 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 110～315 | 16# | ||
| 190～490 | 4*6 | ||
