Large flow, small volume
Large flow adjustment range
Long life, high precision
Positive and negative rotation, no sparks during operation
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P203BL | Stainless steel mounting plate as standard (customizable) | Brushless DC motor | Driver control (Optional with PLC control) | Precise adjustable flow control | DC24V | ≤10W | 175g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers (4 rollers are available) |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC24V | 21～300 | 3*5 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
| 33～320 | 16# | ||
| 20～490 | 4*6 | ||
