High precision, high stability.
Low noise, quiet and stable.
Long life, small size.
Easy tube replacement without tools.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P202DB | Stainless steel mounting plate as standard (customizable) | Brush DC motor | Power-on operation | Fixed flow rate | DC12V、DC24V | ≤8W | 140g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 2 rollers |
| FLOW RATE: ml/min | |||
| Voltage | Flow Range | Tube Size | Tube Type |
| DC12V, DC24V | 15～45 | 14# | BPT Tube/Silicone |
| 55～110 | 16# | ||
