Ultra-low noise, suitable for various environments.
Planetary reduction transmission, stable speed.
Anti-reversal and fall-off design.
Easy replacement without required.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P104DB | Stainless steel mounting plate as standard (customizable) | Brush DC motor | Power-on operation | Fixed flow rate | DC12V, DC24V | ≤8W | 114g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC12V, DC24V | 12～35 | 1*3 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
40～106 | 2*4 | ||
80～190 | 3*5 | ||
160～270 | 4*6 | ||
