Brushless motor control, more stable flow.
Low speed, small size, large flow.
Hidden reduction box, compact structure.
Snap-fit fixed, high maintainability.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P104BL | Stainless steel mounting plate as standard (customizable) | Brushless DC motor | Driver control (Optional with PLC control) | Precise adjustable flow control | DC24V | ≤8W | 110g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC24V | 2～23 | 1*3 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
4～97 | 2*4 | ||
8～185 | 3*5 | ||
12～270 | 4*6 | ||
