High precision, high stability.
Low noise, quiet and stable.
Long life, small size.
Easy tube replacement without tools.
SPECIFICATIONS | |||||||||
Model | Installation Method | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
P102DB | Stainless steel mounting plate as standard (customizable) | Brush DC motor | Power-on operation | Fixed flow rate | DC12V, DC24V | ≤5W | 108g | Temperature 0-45℃, Relative Humidity <85%RH | Standard with 3 rollers |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC12V, DC24V | 9～25 | 1*3 | BPT Tube/Silicone Tube/A60-F/Viton Tube |
25～55 | 2*4 | ||
55～100 | 3*5 | ||
