Micro flow rate design.
Compact structure, mini size, light weight, fine workmanship.
Low noise, smooth running, suitable for gap operation.
Installation method can be customized.
Support PWM speed regulation.
| SPECIFICATIONS | |||||||||
| Model | Installation Motor | Motor Type | Control Method | Function | Working Voltage | Power | Weight | Working Environment | Rollers |
| P101AST | Rubber mounting plate (optional) | Micro stepper motor | Drive control (Optional with Driver PLC control) | Precise adjustable flow control | DC5V | ≤2W | 13.8g | Temperature 0-45℃, Relaive Humidity <85%RH | Standard with 2 rollers |
FLOW RATE: ml/min | |||
Voltage | Flow Range | Tube Size | Tube Type |
DC5V | 0～0.2 | 0.5*1.5 | BPT Tube/Silicone Tube |
0.06～0.7 | 1*2 | ||
0.1～1.4 | 1.5*2.5 | ||
