LFG203 Indoor Carbon Dioxide Transmitter, based on principle the different gases have different absorption capabilities for infrared light in a specific band, it measures the concentration of the measured gas by measuring the degree of infrared light absorption. Compared with electrochemical sensors, it has long life and stability. Imported high-performance NDIR sensor is used for CO2 concentration measurement, with rapid response stable performance and high accuracy wide power supply range, smallsize, easy installation, ideal for indoor carbon dioxide measurement. It is widely used to measure the CO2 concentration in environments such as home, office, factory floors, library warehouses, etc.
Imported high-performance NDIR sensor.
The shell design is light and beautiful, using LCD backlight to display.
Long-term stability and reliability, with ABC self-calibration.
Varieties of output methods are optonal, standard 86 box installaton method.
Output Mode | 4~20mA(3-Wire) | 0~5V(3-Wire) | 0~10V(3-Wire) | RS485(4-Wire) |
Working Voltage | 10-30Vdc | 10-30Vdc | 16-30Vdc | 10-30Vdc |
Sensor | NDIR sensor with ABC self-calibration | |||
Average Current | <45mA | |||
Working Temperature | 0℃~50℃ | |||
Working Humidity | 0-80%RH(no condensation) | |||
Measure Concentration | 0-2000PPM/0-5000PPM | |||
Accuracy | ±(40ppm+3%MV)ppm | |||
Response Time | 2min | |||
Protection Level | IP30 | |||
Service Life | >5year | |||
