High precision, linearity and stability.
Good reliability and anti-interference performance.
Good pressure tightness and high degree of intelligence.
No pressure loss, low requirements for straight pipe sections.
Good corrosion resistance and wear resistance.
Two-way measuring system, which can measure forward flow and reverse flow.
Adopt special production technology and high-quality materials to ensure the stability of product performance for a long time.
| Drift Diameter | 10-3000mm |
| Output Signal | 4-20mA, HART, RS485(optional) |
| Accuracy | 0.50% |
| Power Supply | 20-36VDC, 85-250VAC, battery powered |
| Nominal Pressure | 1.6MPa, 1.0MPa, 0.6MPa(2.5MPa and 4.0Mpa can be customized) |
| Lining Material | Neoprene rubber, Polytetrafluoroethylene(PTFE), Polyurethane rubber, Fluorinated Ethylene Propylene(FEP), PFA, Ceramic, etc. |
| Connect Flange Material | Carbon steel, Stainless steel(304, 316, 316L) |
| Signal Electrode Form | Stationary type, Scrapper type |
| Protection Grades | IP65, IP68 |
| Transmission Distance | Split electromagnetic flowmeter, sensor and converter are connected by signal cable, and the cable length should be less than 100m. |
| Maximum Velocity | 15m/s |
| Electrical Connection | Flange connection, clamp connection, thread connection |
| Fluid Conductivity | >50μS/cm |
| Consumed Power | <20W |
| Ambient Temperature | -10℃-60℃ |
| Electrode Material | 316L, hastelloy B, hastelloy C, titanium, tantalum, platinoiridium, tungsten carbide |
| Ground Ring Material | 316L, hastelloy B, hastelloy C, titanium, tantalum, platinoiridium, tungsten carbide |
| Number of Electrodes | Standard 3 electrodes(Two measuring electrodes, one ground electrode) |
