Working Conditions
Ambient temperature: -20~+40℃ | Rated voltage: 24VDC | Insulation grade: F | IP grade: IP55 or IP68 optional |
Medium temperature: -20~+60℃ | Voltage range: 18~30VDC | Lifetime: 20000 hours | Medium: Cool water, hot water, and other fluid |
Specifications
Model | Selections | Rated voltage (VDC) | Max. Flow rate (L/min) | Max. Lift of pump (m) | Max. Current (A) | Max. Power (W) | Controls |
LFP4024 Series | LFP4024-03006A | 24 | 3 | 0.6 | 0.13 | 3 |
|
LFP4024-04010A | 24 | 4 | 1.0 | 0.23 | 5.5 | ||
LFP4024-04018A | 24 | 4 | 1.8 | 0.23 | 5.5 | ||
LFP4024-05014A | 24 | 5 | 1.4 | 0.31 | 7.5 | ||
LFP4024-06020A | 24 | 6 | 2.0 | 0.42 | 10 | ||
LFP4024-07025A | 24 | 7 | 2.5 | 0.52 | 12.5 | ||
LFP4024-08030A | 24 | 8 | 3.0 | 0.75 | 18 | ||
LFP4024-08040A | 24 | 8 | 4.0 | 0.75 | 18 | ||
LFP4024-09040A | 24 | 9 | 4.0 | 1.0 | 24 |
