| Model | LFP1800J-V1 | LFP1800W | LFP2800J-V1 | LFP2800W | LFP2800J-FD1 |
| Voltage | 24V DC | 36V DC | |||
| Inlet Water Pressure | 0.2MPa | 0.2MPa | |||
| Working Pressure | 0.7MPa | 0.7MPa | |||
| Working Current | ≤4.0A | ≤ 2.8A | |||
| Working Flow Rate | ≥4000ml/min | ≥4000ml/min | |||
| Open Flow | ≥5000ml/min | ≥6000ml/min | ≥5000ml/min | ≥6000ml/min | ≥5000ml/min |
| Bypass Pressure | 1.05-1.2MPa | 0.95～1.15MPa | 1.05-1.2MPa | 1.05-1.2MPa | 0.95-1.15MPa |
| Maximum Current | ≤5.0A | ≤ 5.0A | ≤ 3.5A | ≤ 3.5A | ≤ 3.5A |
