① Self-priming type
| Model | Voltage | Inlet Water Pressure | Working Pressure | Working Current | Working Flow Rate | Open Flow | Bypass Pressure | Maximum Current | Self-priming Height |
| LFP1150S | 24V DC | 0MPa | 0.5MPa | ≤2.1A | ≥1450mL/min | ≥1800mL/min | 0.8-1.0MPa | ≤2.8A | ≥3.0m |
② Normal type
| Model | Voltage | Inlet Water Pressure | Working Pressure | Working Current | Working Flow Rate | Open Flow | Bypass Pressure | Maximum Current | Self-priming Height |
| LFP1150W-P | 24V DC | 0.2MPa | 0.5MPa | ≤1.5A | ≥1500mL/min | ≥2000mL/min | 0.85-1.0MPa | ≤2.2A | / |
| LFP1150W | ≥2200mL/min | ≤2.0A |
