| Model | LFP1300W(A)-B | LFP1300W-B | LFP1400.2W-B | LFP1500W-B | |
| Voltage | 24V DC | 24V DC | |||
| Inlet Water Pressure | 0.2MPa | 0.2MPa | |||
| Working Pressure | 0.5MPa | 0.5MPa | 0.7MPa | ||
| Working Current | ≤2.0A | ≤2.2A | ≤2.4A | ≤2.6A | ≤2.8A |
| Working Flow Rate | ≥2200ml/min | ≥2700ml/min | ≥2950ml/min | ≥3250ml/min | ≥2800ml/min |
| Open Flow | ≥3000ml/min | ≥3000ml/min | ≥4000ml/min | ≥5000ml/min | |
| Bypass Pressure | 0.85-1.0MPa | 0.85-1.05MPa | |||
| Maximum Current | ≤2.8A | ≤3.0A | ≤3.2A | ≤3.5A | |
